A friend recently gave me an RT-654A/TRC-77. Also known as the TRC-77A. The RT-654(*) is the basic component of the “AN/TRC-77” set.
A Deep Dive – probably more than you ever wanted to know:
(“TRC” = Transportable Radio Communications. The designator PRC as used with contemporary field sets indicated Portable Radio Communications. Those PRC sets could be operated while being carried; eg, the PRC-10, 25, 77, 70, 74 etc. The TRC-77 cannot be operated while being carried due to the large HF wire antenna requirements and the fact that the transmission mode was CW only. It was therefore deemed to be “Transportable”, a designation otherwise rarely utilized for a packable set. TRC, but still a relatively unusual designation)
It seems to me that the AN/TRC-77 is noteworthy for being extremely obscure in the historical record. After lengthy research I have found no primary references indicating that they were ever used operationally by US forces in Vietnam although they were used elsewhere – Read on.
However, in my view, this is a very capable, simple, rugged field set. But it requires an operator well trained in morse code and the art of long range HF radio. Add the use of this set to your inventory of TTP’s (Tactics, Techniques and Procedures.)
Don’t go on a long range Recon mission without one.
Above: Parts and accessories comprising the complete set.
A very dependable camp radio up in the mountains…. Got Comms? Yes…..
Night Ops:
Above: Sending out the nightly SITREP from the hide site. Night time is the right time……Radio Silence (and light discipline) has been waived……….
Basic Specifications: (Organizational and Maintenance Manual, Radio Set AN/TRC-77 and AN/TRC-77A, TM11-5820-473-12, October 1965). An excellent reproduction is available from WA5CAB.
Its primary capabilities are 10-14 watts* output from 3 to 8 mc. The Planning Range is “5 to 7 miles” according to the manual. It transmits and receives Morse code (CW) but it can also receive on-channel AM (with BFO Off) or SSB (with variable BFO On). It is configured to be operable with an external J-45 CW “knee key” or the GRA-71 code burst keyer. The transmitter and receiver are each crystal controlled on one of 6 independent, panel-selectable channels.
(* The Depot Overhaul Standard is 2.5 watts minimum with a battery voltage down to 10.0 volts)
It is all transistorized except for the transmitter oscillator tube and the PA amplifier tube. The receiver draw is in the order of 15-20 mA, amazingly low for what it is capable of. Transmit draw is in the order of 3.5 amps, key down.
Power was provided by a BB-447A/TRC-77 wet cell NiCad battery pack. The battery box (a rare item) had connectors for an external 12 volt power source in the event the NiCad battery had discharged or otherwise failed. The BB-447A/TRC-77 was made up of ten, 1.2 volt BB-418/U nickel cadmium wet cells in series producing 12 volts nominal.
These are the same cells as used in the PRC-74 radios as an option for that set. The TRC-77 systems included an AC and a DC powered battery charging system. The DC powered charging circuit was powered by any expedient 28 VDC source and current-limited by a 1 ohm, 240 watt resistor. That’s it. Simple. An operational set in the field with battery weighs about 25 pounds.
The set was designed to work with the GRA-71 Code Burst Keyer via the inclusion of the Cable Assembly, Special Purpose, CX-11389/TRC-77A as seen in the above cartoon. This plugged into the radio Key jack and one end went into the GRA-71. A third connector plugged into the radio battery to directly power the GRA-71. Encrypt your message and then send it at 300 words per minute, BZZZZZT, drop the antenna and boogie to your next location.
The author of the ARRL’s Low Power Communication chapter regarding military radios commented that the AN/TRC-77 is not really a transceiver; that it is actually a transmitter – receiver since both functions were independent of each other. Hmmmmm. Interesting…Upon looking however, the receiver final audio amplifier stage is shared by the transmitter sidetone function. So yes, otherwise, they are electrically pretty independent of each other..
The Planning Range quoted in the manual is 5-7 miles, which is interesting in itself. The radio was developed specifically to meet an Army requirement for a “long range reconnaissance set”. The TRC-77 was certainly capable of producing “long range” in the hands of a skilled operator with reasonable propagation conditions. Even better with a well designed wire antenna versus the supplied end-fed “slant” wire.
However, absent even “fair” propagation, it could produce an easy ground wave or LOS signal reaching shorter ranges, (like 5-7 miles). The PRC-10 and later PRC-25 FM sets that were then becoming standard could also deliver 5-7 mile ranges – so that tactical requirement was already met. How the TRC-77 became documented as a short range HF CW set for “Planning” purposes is a mystery so far.
Above: A size comparison. The TRC-77 and PRC-25 receiver-transmitters are of comparable size however the TRC-77 has a significantly deeper battery box. Read on.
Development
The development of the basic set started in early 1959 after the Army issued a requirement for a new “long range reconnaissance set”. Note that this was many years before the US Army 5th Special Forces Group stood up in Sept 1964 in Vietnam. I think that the timing alone says the TRC-77 was not specifically developed for Special Forces in Vietnam as many have surmised or categorically stated.
The Russians and their East German communist collaborators began construction of the “Berlin Wall” in August 1961. This was not that long after their failed attempt to seal off and starve West Berlin resulting the 1948/49 Berlin Airlift.
When the Army issued this new equipment requirement for long range reconnaissance in 1959, the focus was Europe. However, use by Special Forces and similar units was surely anticipated during the even-earlier requirements development.
Consequently in 1959 the development was started on a “crash basis” at the U.S. Army’s Electronic Defense Laboratory in Mountain View CA. EDL was managed by Sylvania Corporation, an early pioneer in transistor development. This new requirement was released even before the US Army adopted the functionality of the CIA’s 1950’s RS-1 set as the design basis for their new GRC-109, circa 1961.
The Central Intelligence Agency was also interested in the TRC-77. The CIA’s Research and Development Engineering staff issued a monthly progress report in July 1962 addressing Project 2004-211 concerning the evaluation of the TRC-77. The report noted that “the performance of this equipment is very satisfactory”. (Reference 69).
The conceptual design of the TRC-77 was likely initiated by the promise and availability of viable early transistors in the late 1950’s. This held the possibility of smaller, light weight, entirely battery powered HF sets. No heavy, clumsy hand-cranked generator needed for high voltage power amplifier tubes! High current Germanium PNP power transistors like the 2N174 enabled switching oscillators to produce high voltages from a low voltage battery. No more HV machines necessary.
So production was then started by Sylvania with the first 120 units being produced as the AN/TRC-77 (the basic component being the RT-654) in June 1961. That order was completed in May 1962. A follow on order for 970 sets was placed with Arvin Industries with deliveries starting in Sept 1965 as the RT-654A/TRC-77 with some minor modifications over the initial model. My particular example has 1965 date codes on the components but I don’t know when production ceased.
It appears so far that those 1,090 sets of both models was the total produced. Reference (51). Also note the multi-year gap between procurement orders. The Army was apparently having a hard time deciding between the competing technologies that were emerging – and not measuring up. Robust, high power RF output stage transistors were not quite ready yet. Hence the hybrid TRC-77, PRC-25 and even the PRC-47 among others.
The AN/TRC-77 was declared obsolete by the U.S. Army on 2 December 1971 per MIL-R-55253. A relatively short-lived radio set.
Above: A Family Reunion contrasting the 2 different models at a Safe House. The RT-654 flanked on either side by RT-654A models. Note the beveled front panel edges and the different audio connector on the RT-654 “Non-A” model in the middle. The center and right radios were up and running on 80 and 40 meters keeping us in comms with a buddy over 200 miles from here.
The radio on the left still had the stock crystals installed so it was relegated to keeping Radio Havana Cuba under surveillance on 6000 kc. For now.
“Free Territory of the Americas” they call themselves……Got it.
Yes, I did hear this Communist thug on my S-120 and also on my TRC-77! Thank you Hallicrafters for telling it like it was (and continues to be). When the “cure” is vastly worse than the disease.
Known Deployment:
So there I was……
Cartoon from the Organizational Maintenance Manual TM11-5820-473-12
The AN/TRC-77 was first fielded by Long Range Reconnaissance Patrol (LRRP) units of the US Army Southern European Task Force in the winter of 1961-62 as the “then new” AN/TRC-77. It was utilized by the V and VII Corps and Third Infantry Division LRRP units in Europe. The unit communicators received TRC-77 training from Sylvania Corporation technical representatives as the equipment arrived in theater.
Prior to that, LRRP units in Europe were equipped with the RS-1 (and then later transitioning to the AN/GRC-109) which had replaced the AN/GRC-9. The AN/GRC-109’s were later replaced in Europe (at least for some applications) by the heavy AN/PRC-74 frequency-agile SSB/CW set which in turn was nominally replaced by the (older) AN/TRC-77 for long range HF CW communications (again in some applications and at different times). (Reference 38).
These LRRP units left the AN/TRC-77’s in Germany when they subsequently deployed to Vietnam in mid-1968, just taking their AN/PRC-25 FM sets with them (Reference 41). This 1961-62 time frame is the earliest reference I can find on the operational deployment of the AN/TRC-77(*). (The first production radios did not leave the Sylvania plant until June 1961.)
A modified “TRC-77-AM” was then evaluated by Stanford Research Institute for the Advanced Research Projects Agency (ARPA) Project AGILE in 1963 on the Maylay peninsula in Thailand. (ARPA had contracted with Sylvania to modify ten TRC-77 sets to include an AM voice capability and for at least 3 TRC-88 SSB/CW sets.)
It was evaluated along with the TRC-88 CW/SSB set, Hughes HC-162, TRP-4 and others (An AN/GRC-9 was also present but its performance was apparently not tabulated in the comparison data.) The TRC-77 was specially modified to include an AM voice capability so “it” could be compared with the other sets in voice communications over 5, 10 and 22 mile jungle propagation circuits. Reference (65).
The TRC-88 did provide USB voice (along with CW as indicated by the XMTR Mode switch but CW keying was never actually installed in these sets.) It is otherwise a close derivative of the TRC-77 “non-A” model. Below is a photo of an RT-654A/TRC-77 (top) and an RT-665( )/TRC-88 set for comparison. The lineage is obvious. For more information on the TRC-88 take a look here: TRC-88 Radio Set
In the Thailand comparison evaluations, the SSB HC-162 generally produced more reliable voice communications during these tests. This was significantly assisted by its frequency synthesizer’s ability to avoid on-channel interference which was formidable in SEA during those times (Reference 47). Eventually a modified version was produced after “extensive redesign” was done.
The HC-162 evolved into the AN/PRC-74 which became the Special Forces defacto issued HF SSB voice manpack radio set later on.
In the December 1963 ARPA semi annual (and possibly final) report on Project AGILE communications equipment, Stanford Research Institute (contractor) stated that none of the HF radio sets being evaluated in Thailand “were recommended for immediate procurement”. Absent later documentation surfacing, it appears that this recommendation ended the development and procurement of the AM-modified TRC-77 as well as the TRC-88 sets. (Reference 66).
More to follow on the TRC-88. Anyone got a manual or schematic?
Equipment like this was also provided to our NATO allies for their use as well. Below is a photo from PA3ECT’s nice website showing a relaxed Netherlands Special Forces Commando operating CW with a TRC-77 from what appears to be a cave, hut or bunker. His arm is resting on what may be a cache burial container. (photo circa 1964)
The Dutch are well experienced in enemy attack and in resisting foreign occupation. I’m sure this soldier knows what he is doing. Respect.
Hans’ site also has a nice post on the restoration of his TRC-77. His set has a BNC antenna connector and a different type of identification label. Maybe some sets were built there under a licensing agreement of some sort? PA3ECT
It is also possible that the Netherlands military took their available TRC-77’s and then modified them for their specific use; the BNC antenna connector being a possible example. A known example is they took their RS-6 sets and modified them to incorporate a transistorized (versus Vibrator) DC power supply and changing to more robust system connectors. All excellent modifications.
The TRC-77 was also apparently provided to the government of El Salvador as it tried to fight off the communist insurgency during its civil war. In an internal CIA memo dated 9 December 1982 “The Situation in El Salvador”, the author noted that the insurgents had captured “a dozen TRC-77 radios” from government forces along with a quantity of weapons and ammunition. (Reference 68).
Without evidence, I am guessing that this may be a typo; they were more likely PRC-77 radios but the report says what it says.
The TRC-77 – PRC-64 convergence: From October 1964 to January 1965 the US Army 5th Special Forces Group evaluated the AN/PRC-64 in Vietnam. As part of that experiment a TRC-77 was also evaluated as a “comparison” set. (Reference 52).
The photos on page 69 show the PRC-64 and TRC-77 being deployed side-by-side. Something you would not need to do operationally so I conclude those photos were taken during the evaluation comparison tests. That reference described the TRC-77 as “experimental”. Incidentally, the photo in Reference (52) mis-identified the TRC-77 as the PRC-77. Thanks to Bill, W8FIX for pointing that reference out to me; see his comments below. It is possible that the “Thailand ARPA” radio was the same one that was evaluated in Vietnam.
The AN/TRC-77 (unmodified, stock CW set) transceiver was also used by the US Army at the Ft. Clayton Jungle Warfare Training Center in Panama in October 1964 again as a comparison “control” while the AN/PRC-64 was being developed and evaluated to meet Special Forces jungle warfare requirements (Reference 37).
As noted above, production AN/TRC-77 units were fielded in Europe with Company C, LRRP units of the 58th Infantry in Germany. It was fielded by them along with the AN/PRC-64 which was reported by them as being “greatly superior” to the AN/TRC-77 (Reference 37).
From the perspective of “Mudborne” troops, I would assume that a large part of that assessment was based upon the small size and weight of the PRC-64 versus anything else. If you could make your Comm Window CW contact with a TRC-77, you could probably also make it with the PRC-64. The PRC-64 has about 3 db less transmitter power output but that is not much of a difference on the receiving end of the contact. However the difference in weight is substantial while being carried along with all their other gear.
Anecdotal information indicates that AN/TRC-77’s were possibly also used by the Australian Army. That makes sense as Australian Army signals personnel (including Major W.B. Fegan, Royal Australian Signals) were involved in the development of specification requirements for the AN/PRC-64 as a jungle patrol radio which they subsequently used themselves in Vietnam.
During that development, Major Fegan also contributed a critically important, but otherwise easily dismissed observation based upon the Australians earlier jungle warfare experience in WWII coastwatcher ops and later in Borneo. “The most important component of a man pack radio system is the man.” Indeed. Keep it small, lightweight and simple. Sounds like the PRC-64.
However, the online history of the Royal Australian Corps of Signals makes no mention of their use of the TRC-77 while deployed to Vietnam, but it does detail other tactical equipment that they employed there. That includes the PRC-64, PRC-25 and 77, GRC-106, PRC-47, VRC-12 etc. (Reference 55).
Vietnam deployment? (No.) The US Army provided “only a few prototype models of the TRC-77, an experimental high frequency set” to the government of the Republic of Vietnam at the request of President Diem for his 20 nascent Commando units. (Reference 3 states that these few prototype sets were provided in 1960. That date is interesting since the first radios were not even out of production until June 1961. So any “prototypes” provided must have been just that, and not production models sitting unused in storage as some have surmised.)
The AN/TRC-77’s may not have been used operationally by U.S. forces in Vietnam at all, as (so far) I have found no authoritative data to confirm its use by our forces there beyond the 1964 comparison evaluation. Anyone?
The AN/PRC-64 DID receive further evaluation by the 5th Special Forces Group in Vietnam in late 1964 and early 1965 but no mention of the AN/TRC-77 being further evaluated alongside the PRC-64 at that time. Incidentally, the 5th SFG evaluators in Vietnam found the AN/PRC-64 “far superior” to the AN/GRC-109 in patrol operations (this authors emphasis). This assessment was made primarily on the merits of its size, weight and ease of setup (their words) as compared with the GRC-109. It was also noted that both sets provided approximately the same level of performance. (References 37 and 40).
Transistor technology for portable military radios was maturing and catching up. However the all-transistor AN/PRC-64 itself apparently didn’t see much more than evaluations in Vietnam by the US Army. That small size and light weight came at a performance and operational flexibility cost. It required a unique dry cell battery that provided 3 different voltages; a type used in no other radio set. Additionally, its 1.5 watt AM voice transmitter capability was evaluated as being unreliable, especially when used outside the Mekong Delta area with its high ground conductivity and communications-friendly flat terrain.
I can also find no authoritative references to the use of the PRC-64 or TRC-77, or intent to be used, by “Military Intelligence” or as a “spy” radio – such an imprecise term. Internet hype notwithstanding. (The PRC-64’s predecessor Delco 5300 WAS used by the CIA however.) As noted above, the CIA did at least evaluate the TRC-77, however I have found no evidence that they actually used them operationally.
A Military Assistance Command Vietnam Studies and Observations Group (MACV-SOG) Communications Officer report in early 1969 (Reference 1) listed the equipment held in inventory and being used by those Special Forces units in Vietnam. MACV-SOG was the parent Command for joint service unconventional warfare units, including Army Special Forces. They were the primary users of long range portable HF gear in Southeast Asia. No mention of the TRC-77 in that report, however it did note this as a matter of interest:
“The AN/PRC-64 (lightweight CW and Voice Set) for U/W [Unconventional Warfare] is receiving little use now but should remain in inventory for intermediate range (beyond range of PRC-77 but not requiring PRC-74) operations”. This tends to shed light on the thinking regarding portable HF CW radio systems at that time and place by units most likely to use them.
(A total of 500 AN/PRC-64 sets were produced, including those delivered to the US Army and Australian government.) Reference (38).
There is a lot of speculation, assumptions, YouTube videos, E Bay sales claims etc. about the use of the TRC-77 in Vietnam. (and therefore absolutely true…!)
As a green, Vietnam era radio, those assumptions are easy to understand given all the “circular research” out there on the Web. Significantly, there is no mention of the TRC-77 in the declassified MACV-SOG Communications history although the PRT-4, PRR-9, PRC-25, 64, 70, 74, 77, GRC-109, RS-1, FRC-93 (KWM-2A) etc are all discussed. (References 1 and 7).
Aside from anecdotal reports of “used” TRC-77 radios showing up in Australian surplus shops, most of the ones I have seen, or photos that I have seen, appear to be in pristine, unused – unissued condition. The set I have seems to be an exception; the front panel ID tag carries a different serial number than the number stamped on the chassis. It also shows some internal repair evidence and the usual service wear but most likely not by “hammering” by a previous civilian owner.
The TRC-77 was originally developed to meet a US Army operational requirement for “long range reconnaissance units”. Some time later the AN/PRC-64 was being evaluated and then the AN/PRC-74 and (later on) PRC-70 were appearing in Army supply channels. Coupled with the Army’s dwindling interest in HF, and particularly in HF CW-only radios, conjecture is that was likely the reason the AN/TRC-77 did not see wide acceptance.
Also, sustained operational combat comms on the same frequencies of a non-frequency agile radio is a significant OPSEC problem. However this was somewhat routine by US forces in Vietnam as they often traded security for speed. We were starting to realize the obvious consequences of that. The December 1969 capture of the Viet Cong’s “A3 Technical Reconnaissance Unit” in South Vietnam (among other events) affirmed their effective COMINT capability against sloppy US communications security on voice and morse code circuits. (Reference 63).
Which equipment appeared in what numbers, in which theater, in which units, for which mission, in which time frame is always a nebulous thing. There are few “absolutes”. Again, more research needed here; a few weeks in the National Archives should sort that out…
Neither the AN/TRC-77 nor the AN/PRC-64 appear in FM 31-20 (December 1965) Special Forces Operational Techniques, although the AN/GRC-109, and particularly its preferred antennas are prominent. It also mentions the use of the AN/GRC-87 (GRC-9) (Reference 42).
The AN/TRC-77 is listed in Communications-Electronics Data, FM24-19 dated October 1966, the one and only TM I have found that includes it. It does not appear in the US Army Infantry Communications Data catalog dated 1973 although the PRC-25/77, AN/PRC-74 and 70 are listed under Portable / Special Equipment. (Reference 39).
The AN/TRC-77 also is not listed in FM24-24, Radio and Radar Reference Data, December 1983 (Reference 36) however the AN/GRC-109, PRC-47, PRC-64A and PRC-74 DO appear.
Aside from TM24-19 and references (3 and 52) above, I have yet to find any reference to it in similar books or in US Army documents in my collection or on the Web. That includes other Field Manuals, other Technical Manuals, Training Circulars (TC), Infantry school class notebooks etc. The specific manuals for it, Organizational Maintenance Manual TM11-5820-473-12 is available from Robert Downs as a nice reprint. TM11-5820-473-35 can be found online. Originals of either document seem to be rare.
All this tells me where the TRC-77 probably wasn’t used operationally.
So, absent any new, authoritative reference surfacing (aside from the 1964 comparison experiment noted in Reference 52), I’m calling claims of the operational use of the AN/TRC-77 by any US forces in Vietnam as “Busted”.
Is that a problem? Heck no! I am sure that they served the Army’s Long Range Reconnaissance Patrol units in Europe very well. For use on the Ham bands, the TRC-77 still has way more “street cred” than any plastic ricebox ever made by KenYaeIc.
Back to the radio itself:
Above: The RT-654A built by Arvin Industries. Note the U-228 “new family” panel connector for the H-140/U, U-229 headphone plugs. The RT-654/TRC-77 (unlettered model built by Sylvania) had a standard 1/4 inch earphone jack instead. The “plain” and A Model also have minor internal differences; mainly the power connectors, LC circuit tuning differences, minor component changes and panel machining.
Note the shipping protectors on the panel handles. Split PVC tubing pieces. Owners seem to like to keep those on for some reason. Those black speckles on the front panel seem to be present in some of the photos of these radios that I have also seen. Upon close examination they appear to be contamination on the panel under the surface paint. Hmmm, Camo? HiHi
This radio has a very simple “user interface” in today’s parlance. A CW-qualified Ham, or a CW-qualified Army operator could be taught how to operate this set in less than 3 minutes. An additional 5 minutes of on-air tuning up to a wire antenna would complete checkout. Making a few on-air contacts and you are Good to Go. Very simple, soldier-proof.
The battery boxes for these radios seem to be rather hard to find. Boxes that saw service may have been damaged due to spilled potassium hydroxide electrolyte corroding the aluminum box.
So absent a battery box I made one from some scrap plywood and a few hardware store latches and corner protectors. This box holds two 12 volt, 8 Amp-Hour Sealed Lead Acid batteries in parallel – providing more capacity than the original 14 AH NiCad wet cell battery.
I could have used modern, light weight Lithium based batteries but they are fussy about charge and temperature control and potentially a fire hazard if slightly abused. SLA’s are pretty bullet proof.
Wiring now includes a 5 amp fuse and a 2 foot jumper for powering from an external battery if necessary. Not pretty, but it does the job:
“No combat-ready unit ever passed inspection.
No inspection-ready unit ever passed combat.“
Murphy’s Laws of Combat
Above: My DIY system includes alligator clips for an external battery and I used Anderson Power Pole 30 Amp quick disconnect connectors. The power connector I have is a Bendix 10-419344-2S. It looks like an Amphenol PT06E-10-2S might also work. The “2S” indicates a 2- pin socket/female type.
The connectors also enable convenient access for my solar panel or an AC charger to charge the batteries. Room for spare fuses, antenna wires, Commo Plan, One Time Pads, schematic set, etc. inside.
Above: The 12 volt gel cells being charged by a small “automobile dashboard” solar panel. These are designed to keep a car battery “trickle charged” while sitting on the vehicle dashboard in the sun. This one is capable of pumping 150 milliamps into the paralleled SLA batteries. This is about 10 times the receiver current requirements – so one hour of full sun operates the receiver for about 10 hours.
One hour in full sun will also power the transmitter for a couple of minutes of “key down” time. More than enough for many CW casual contacts with its inherent low duty cycle. Indefinite Ops with this simple setup (and it fits in my ALICE medium pack). Of course a larger panel like my 20 watt unit will permit a higher duty cycle at the Forward Operating Base.
Above: The DIY battery box clipped to the R/T. It has the same external dimensions as the original BB-447 battery pack.
The radio does not have a purpose-made carrying harness or bag. It was probably intended to be lashed to the then-standard plywood pack board. However there is a Bag, Cotton Duck, CW-618/TRC-77 that is provided to carry the associated accessories, probably to include a spare battery, see drawing above.
The radio was probably out of active service well before the ALICE packs came along (1973) as basic 782 field gear. However the ALICE Medium pack is a good fit for the radio, but when clipped to the battery pack it does not fit in the internal radio compartment which was designed for the PRC-25/77.
Above: The radio, with battery attached fits well inside the main compartment of the trusty Medium ALICE pack. Seen here also rigged with the aluminum pack frame and cargo shelf (not visible) for a more comfortable carry configuration. All the peripheral gear including the LS-454 speaker, the headset, J-45 key, antenna and counterpoise components, message book and government issued Memorandum pad and Skilcraft pen etc all fit in the pockets along with space for other mission-essential items if needed.
This is a complete field set, ready to go for a week-long “camp trip with comms”. The heavy speaker is not necessary (nor is it a part of the basic system), but it is handy for monitoring the Alert Net while engaged in other covert activities at your hide site.
Like flipping the steaks…..
Above: The first field tests with the new battery box. I was running a issued-equivalent antenna; on 7050 kc it was a 25 foot slant wire with two 50′ ground radials made from rather springy WD-1/TT infantry field telephone wire.
Above: Forward Operating Base (FOB) “Red Coffee”: The TRC-77 in the Medium ALICE Pack, LS-454 speaker remaining in the center, external pocket. Here feeding a 50 foot “Bush Antenna” with radials laying on extremely dry soil – but the chassis was still “hot” with RF on 3560 kc.
So I installed a tent-stake wet ground in addition to the radials. Problem resolved, no hot chassis, good signals in and out of this location. On this campout I had solid CW comms with my buddy, day and night on 7050 and 3560 respectively. A 78 mile NVIS shot with this 10 watt transmitter. I also worked many other CW ops up and down the west coast with this setup.
Of course with a balanced antenna like a dipole the additional ground stake is unnecessary. As in this deployment on Brannan Island along with the PRC-174 standing by for voice ops.
Oops, Time to refuel! QRX.
Observations on the Receiver:
The 11 transistor receiver is amazingly sensitive. With the chassis out of the case, and no antenna connected, I can clearly hear Radio Havana (from California) in the evening on 6000 kc, one of the “stock” crystal channels originally provided. The Castro boys’ communist propaganda outlet is plenty powerful for sure, but this is pretty impressive receiver sensitivity… Bench tests indicate a very usable CW SNR with a 0.1 microvolt input and it is probably usable below that. I can’t measure any lower due to the leakage from my URM-25 signal generator around the attenuator!
The stock BB-447A/TRC-77 rechargeable NiCad battery provides 14 Amp-Hours of capacity at 12 volts. The manual states that the BB-447A/TRC-77 battery will run the 20 mA receiver for 30 days. 24/7. Non-stop. Pretty impressive. The receiver will also work quite well for around 24 hours just using a common 9 volt “transistor radio” battery.
The RT-654A receiver is very simple to tune up on-channel. Just adjust the “RF” (antenna) and “Mixer” (actually the RF amp collector) circuits for maximum on-channel signal to the headphones. Requires a signal source or a generator like a URM-25. Simple. The receiver has an AGC circuit, active in the AM mode, controlling the RF amplifier, mixer and first and second IF amplifiers. It has an RF Gain control for the same circuits (the AGC is disabled for CW operation) and a volume control.
It will drive a speaker quite well. The BFO is adjustable. With a 455 Kc IF selectivity quoted as 6 Kc (6 db down) and 11 Kc (60 db down), it sounds very good on AM and very easy to work CW even if something is “off” a little. (The selectivity is not so great on 40 meters during a CW contest! – You are not doing THAT while deployed anyway).
Above: The RT-654A set internals. The transmit crystal sockets are on the left, the receive crystals are along the rear; each set has a spring-loaded cover to keep them properly seated. Note the provided adapter to permit the use of the specified CR-18A/U crystals in the small HC-6/U metal holders to fit in the older FT-243 sized sockets. See below “On Crystals“.
The earlier RT-654 (“Non-A”) shown below is similar but with the additional complication of moveable jumpers (called “Tuning Links” in the manual). These jumpers can connect an additional 56 pf fixed capacitor across the variable tuning capacitors in each of the receiver RF and Mixer stage tuned channel circuits. The original RT-654 used 1-90 pf variable capacitance piston capacitors to tune the fixed inductors in these tuned circuits. However, 1 to 90 pf was insufficient to cover the entire tuning range of the radio from 3-8 mc. So the designers added these jumpers to allow the insertion of the additional 56 pf capacitors in parallel to enable the each individual circuit to tune below 3.8 mc.
No big deal, just set them to the necessary positions before you start the alignment.
Above: The RT-654 receiver RF front end circuit board. The receiver crystals seen here at the rear of the chassis are Channels numbered 1-6, left to right. Their associated Channel Tuning Links are reverse-numbered 6-1, left to right. The alignment tool points to the Mixer link for Channel 1. Note the small rectangular 56 pf capacitors above the link sets. The Antenna tuning links are the ones furthest from the crystals at the top of this photo.
In this photo, the mixer and antenna Tuning Links for Channel 1 are moved towards the front panel (top of the photo) to connect in the 56 pf capacitors since my Channel 1 crystal was on 3550 kc at the time. The other links are towards the rear panel for the rest of the channels in this radio because they were all higher than 3.8 mc, Why is it important to note all this detail?
Because the alignment instructions in the AN/TRC-77 and AN/TRC-77A Radio Sets Manual (DS, GS and Depot Maintenance, TM11-5820-473-35, June 1966) are incorrect.
Page 3-12, Paragraphs 3.7 (b)(5) (b/c) says “For channels receiving frequencies between 3 and 3.8 megacycles the RF and mixer links should be positioned closest to the rear of the unit.” [and] “For channels receiving frequencies from 3.8 to 8 megacycles the RF and mixer links should be positioned closest to the front of the unit.”
They got the link position instructions exactly backwards.
The earlier Organizational Maintenance Manual, TM11-5820-473-12, October 1965, has ambiguous Link position instructions: It does not clearly describe what “top” and bottom” means in the placement of these Tuning Links. If you are having problems tuning your RT-654 “Non-A” receiver, this may be your problem. Heads up.
(The RT-654 “Non-A” Transmitter also has a set of Tuning Links in the PA output stage. The manual is correct in setting the position of those Tuning Links.)
The receiver output stage is designed to drive a 600 ohm load, usually the H-140A/GR headphones (RT-654A). The RT-654 has a standard 1/4 inch earphone jack on the front panel, the RT-654A accepts the 5 pin U-229 connector common to the “new family”, VRC-12 audio accessories. The set will drive an LS-454 speaker (with rewired cable connector) to room-filling volume. When used with the LS-454, the combination has a nice peaked frequency response of around 800 cps, perfect for CW but it still sounds good on AM.
Note to self: The gain of the receiver AF driver stage, Q54, is quite sensitive to 12 volt power supply variations. Not operationally noticeable but any slight transients/noise on the 12 Volt (non-battery) type of external supply appears in the audio output. Independent of the setting of the Volume control. Additional 1000 uF PS filter cap added to mitigate.
Observations on the Transmitter:
The transmitter is a MOPA type, Master Oscillator (a 3B4 tube) and a Power Amplifier, (a 2E24 instant heating cathode type). This is the same PA tube as is found in the RT-66, 67 and 68 FM sets. It is essentially a 2E26 (as found in the RS-1, RS-6 and GRC-109 sets) but with a directly-heated “instant on” cathode. The 3B4 is also a directly heated cathode type and it is also found as the PA tube in the PRC-6 FM walkie talkie and as PA drivers in the RT-66. 67 and 68. In this transmitter both tubes are up to temperature in the time it takes to move your hand from the Transmit-Receive switch to the CW key.
There are 4 transistors in the HV power supply; 2 oscillators, 2 in the voltage regulator. There are 2 transistors in the grid-blocked keying circuit plus a mysterious 4-layer Shockley diode sidetone oscillator.
The manual’s Operating Instructions, Chapter 3, Section II, “Operation Under Unusual Conditions” Paragraph 3.5 states to let the transmitter “warm up” for 2 minutes after turning the Function Switch from RCVR to XMIT. WHAT? That is certainly unnecessary, the transmitter is stable and ready to go almost instantly. Two seconds warmup, maybe. How would one operate 2-way or in a Net with that restriction? Section III, also titled “Operation Under Unusual Conditions”, Paragraph 3.9, discusses the usual “Operation at Low Temperatures” (no mention of a “warmup” requirement there) and “Operation Under Tropical Conditions” (Standard fare in Army Tech Manuals).
It is possible the intent was to stay in the XMIT mode for 2 minutes at very low temperatures to let a very cold BB-447A NiCad battery warm up a little with “key-up current” and then produce rated voltage. That “warmup time” under normal operating conditions (implied) has to be an error by the manual’s tech writers and the engineers didn’t catch it. That makes more sense, but if so, that precaution is mislabeled, misplaced and badly confusing. Sloppy editing. Or maybe a “typo”. Two seconds??
Once the Function Switch is in the XMIT position the oscillator runs continuously and the telegraph key keys the PA stage via grid-block keying. Very stable, no chirp. Since the transmitter has an independent Sidetone Generator you cannot hear your own signal (or oscillator Backwave); because the receiver is muted. Sidetone is also necessary when operating on separate transmit and receive frequencies even if the receiver was not muted.
A note of caution: It is easy to bump or forget to switch the transmitter BACK to receive while running tests, distracted etc. It is not a full break-in/QSK radio. There is no indication other than the switch knob that it is in transmit mode so the HVPS oscillator just keeps running – eventually killing your battery. During transport I simply disconnect the battery.
Minor problem: The set is made with high quality components and has been very reliable in almost weekly operation in the field and here for the past 7 years. However it recently failed to go from receive to transmit reliably. Turns out S-302 was beginning to fail with a high resistance when closed. It provides primary power to the HVPS oscillator and PA circuits when in XMT mode..
It is a 5 amp rated microswitch, cam-driven by the rotary “OFF RCVR XMT” panel switch. TX key down current is about 3.3 Amps at 13 volts but there is an additional startup surge of quite a bit more as the HVPS capacitors charge. This has apparently caused a premature failure in this switch (this example was built 58 years ago). I know of another TRC-77A with the same fault.
S-302 with the red wires is seen in the below photo to the left of the Antenna Loading toroid coil. A fairly easy replacement.
Above: The set is a “hybrid”. That’s the 2E24 power amplifier tube in the black shield on the right. The high voltage power supply generates 400 volts DC for the PA tube, 120 volts DC for the oscillator tube and -175 volts DC for the PA grid blocking and operating bias. The tube filaments are fed with square wave AC from the power oscillator.
PA Tube removal, I get a lot of questions about this. There is a screw on the side that holds the shield to the chassis – so remove that screw.
The shield is a “bayonet” type so it required a bit of rotation (use a flat blade screwdriver in the slots to “pry” it to rotate). Once rotated it can be pulled off carefully. Not a lot of clearance in there…I think the tube can be pushed out from below the socket, pushing on the center post. Takes some doing but it works..
The HV power supply includes a 2-transistor voltage regulator circuit to keep the outputs within specifications if the primary input voltage went as high as 17 volts from a vehicle battery being charged by a generator.
The power supply is reverse-polarity protected by a series diode. The HV power supply uses a conventional 2N174 DC-DC oscillator circuit that flips open exposing some receiver circuitry. The oscillator runs at around 2.2 Kc to keep the efficiency high but I cannot hear it in the receiver audio or in the transmitted signal. Good shielding, filtering and bypassing design here.
When the function switch is in the XMIT position the set draws 2.01 Amps, key up. Key down it draws 3.34 Amps. (both measurements made with 13.00 Volts at the power connector.) The Depot overhaul acceptance criteria state that the set must produce a minimum of 2.5 watts RF output with a battery that is down to 10 volts.
One strange test noted in the manual is to measure the acoustic noise generated by the radio while in the transmit mode, key down. The test is to be performed in a sound-proof booth with a calibrated microphone and recording system. Maximum sound pressure levels are specified for various audio frequency ranges. Presumably so the enemy could not hear the set while in operation – from sounds coming from other than the earphones. Danger Close…I have not seen that test requirement in any other radio. I wonder where that came from? I sure can’t hear anything, even the high voltage power supply oscillator.
This radio has difficult access to some internal components due to its compact construction. The only “modular” component is the HV power supply. But it is beautifully built and well protected environmentally. The aluminum parts are clear-anodize passivated and the glass-epoxy PC boards are protected with a clear epoxy conformal coating. A hefty panel-case gasket and sturdy case snaps along with control/connector gaskets keeps it dry inside.
Tuning the transmitter to the channel frequency is very simple, requiring only a tuning tool and a VOM on 2 test points, which measures the Driver plate current and the PA plate current to indicate resonance. The set incorporates an under-chassis switch for “Tune” and “Operate”. In the Tune position the B+ to the oscillator plate and screen and the screen voltage to the PA plate is reduced for tuning adjustment. When done, just switch back to Operate – if you forget, the switch automatically moves to Operate when the chassis is slid back into the case. Handy, easy on the components, Soldier Proof. This switch is designed to protect the power supply transistors and the 2E24 screen grid from excessive heating (melting) while the transmitter is being tuned (off resonance). Follow the procedure!
When tuning up into an antenna for a transmission, place the radio in Transmit mode, hold down the key and turn the “Ant. Tune” switch to one of the 12 detent positions that produces maximum brilliance (antenna current) from the Antenna Tuning Indicator lamp on the front panel. Simple, no thinking required. You’re good to go. The tuning lamp circuit includes a front panel switch to reduce the brightness when driving very low impedance antennas; the lamp can also be bypassed during light-discipline conditions (and get a little more RF output – not that the guy on the receiving end could possibly even notice).
Above: Key down, Antenna Tune in position 3 delivering power to the antenna. On this first trial I worked KF6GC in Atascadero CA, a 178 mile shot on 7050 Kc, mid-day. Easy. My second contact was with K3SEW in Howard PA, 2350 miles again on 7050 Kc (using a dipole). Ron is always good for a cross-country radio check on 7050. Five to seven miles indeed. This set is easily capable of cross-continent comms on a fairly routine basis.
Simple Keying modification: I added an internal wire from the Key connector over to the U-228 Phones connector on the front panel. This wire now connects the keying circuit to Pin C of the Phones connector which had otherwise not been connected to anything.
This enables keying with the newer KY-116/U or the KY-562/U Knee Keys that use the U-229 connectors. Pin C is the PTT line for standard VRC-12 equipment thus also enabling use of an H-189/250/350 handset to key the transmitter as a backup capability if needed.
On Antennas:
Antennas provided: AT-1098/TRC-77, is a set of 3 color-coded wires (white, purple, red) of length 57, 40 and 25 feet respectively, depending upon the frequency band in use (see table in manual). This slant wire is a quick, simple, compromise antenna, although not particularly good for “long ranges”. But consistent with “5-7 miles” planning ranges.
Note that each of those 3 wires is shorter than one quarter wavelength at the lowest frequency in the range specified. This means they will all present a capacitive load to the radio with a fairly low resistive component. The simple output network was designed to drive this capacitive load to avoid large tuning excursions possible on either side of resonance – requiring an additional adjustable reactance. The counterpoise assembly consists of two fifty foot “ground” wires.
Some really well designed field evaluations were done by the US Army in Panama trying to address the issue of short radio ranges in jungle environments. These experiments contrasted the AN/TRC-77 with the AN/GRC-19 utilizing different antenna types in different configurations.
They tested slant wires, verticals/whips, dipoles, inverted dipoles, wires in the tree canopy etc. Short answer: The low horizontal dipole was overall most effective. No surprise there for skywave work. An interesting read: Interim Report on Tactical Jungle Communications Study, Reference 87. Lessons learned also apply in tactical deployments outside of “jungle” areas.
Sam, a veteran RTO with LRRP’s in Europe and Rangers (see his interesting comments below) offered observations on antennas used with the TRC-77. He found that the “issued” end fed slant wire antenna was not very effective so they used dipoles instead. He described the performance difference between the slant wire and dipole as “night and day”. (Reference 58). No surprise there – end fed slant wire antennas are pretty useless for regional “NVIS-type” tactical comms, especially with low transmitter power. But they are easy to throw up into a nearby tree.
“What’s the best antenna?” The one that works….
If driving a resonant (no reactance) antenna such as a quarter-wave wire or a longer (inductive) antenna, the match circuitry may not be transferring the full power that it is capable of. The set uses a 12-tap toroidal inductor in series in the output network to approximately tune out that nominal capacitive reactance and match to the resistive component of the specified, electrically short antenna. (Simple, but note there is minimal harmonic suppression.)
I have operated it many times on 40 meters into a resonant dipole. The output ANT TUNE indicator gets brighter as you turn the ANT Tune switch all the way down to position 1. (Position 1 removes the toroid inductance completely from the circuit.) But you can’t remove any more inductance. This indicates a likely mismatch but it will be usable anyway. The output components may be seeing higher RF voltages in this configuration but I would assume a conservative component selection was used. These are engineering details, it will work. (Note that the Depot performance acceptance standards are measured while using a 50 ohm resistive dummy load.)
The AT-1098/TRC-77 also includes those two 50 foot “counterpoise” wires to be laid out on the ground 90 degrees apart and connected to the Ground terminal. See cartoon above. They will provide a low impedance ground return for those slant wire antennas at around 4.7 mc where they are a quarter wavelength long. They are less effective at other frequencies, particularly at the high end of the radio coverage where they are nearing a half wavelength long. (At those frequencies they present a high impedance, the radio doesn’t “see” them, so the antenna system does not benefit from them very much. “Hot chassis”, “won’t tune” etc.)
How about a resonant dipole antenna connected directly to the antenna terminals – no feedline – as an expedient antenna:
Above: The radio connected directly to the two dipole legs (brown wires, 66 feet each) for 80 meters, no coax/transmission line, the Hasty Dipole. This balanced antenna works very well with the TRC-77. However, running this same antenna setup, now on 40 meters, makes each dipole leg a half wavelength long on 40 meters. That presents a very high impedance to the radio and it will not “load”. No Tuning Lamp glow, no change on the field strength meter at any Ant Tune position. Bad mismatch, little power transfer to the antenna. Not recommended. So use two quarter wave wires on your operating frequency:
Above: Running a Hasty Dipole Antenna on 40 meters with two, quarter wavelength legs connected directly to the radio. Loads properly. Shown above chatting with a guy who was located near Glacier National Park, 450 miles away from Paulina Lake here in central Oregon. This antenna is quick and dirty – and works very well with the TRC-77. That little solar panel keeps the battery charged, see below.
I have found that the transmitter will load properly on both 80 and 40 meters – while using a 60 meter half wave dipole antenna fed with the particular length of coax in my kit. Although I currently do not have any crystals for 60 meter operation, that antenna is in my kit and makes for a good compromise in the field. One efficient antenna for both bands. Improvise, adapt, overcome. (note to self: measure the length of the coax in the kit.)
I have also tried the set in the field with a single-wire half wave “Bush Antenna” up into a nearby tree as an experiment on 40 meters (chassis grounded to a wet stake) . That set up was actually a quarter wave wire for 80 meters (66′) being used on 40 meters – and hence a half wave on the 40 meter band). This type of antenna also presents a high enough impedance that the antenna current is correspondingly low – and as a result the Antenna Tuning lamp does not glow. At any setting. So you cannot set the Ant Tune switch to produce maximum power without a field strength meter. And it does not “load”.
The design engineers knew all this – hence the AT-1098 lengths are designed to present a much lower impedance than a half wave wire. Also, with the half wave antenna the chassis was HOT with RF despite the ground radials. A tent stake ground took care of that (See above photo) but the end-fed half wave antenna basically does not work with this set, at least of 40 meters. It was worth trying. Incidentally when using a low impedance antenna the tuning lamp is quite bright in a darkened campsite. The light attenuator switch is an important tactical feature.
Above: Reliable, long range CW communications with the TRC-77 from a poncho hootch at a remote campsite. Dipoles in the trees. The GRC-109 on another circuit.
For more information on the field antennas I use with this set and other portable radios, see Portable Field Antenna Kit
On Crystals:
The TRC-77 design requirement is for type CR-18/U crystals in the HC-6/U holder. That spec (currently MIL-PRF-3098/3F series) is for a fundamental mode, parallel resonant crystal in a 32 pf load circuit.
This radio needs a separate crystal for each transmitter and receiver frequency. For a total of 12 crystals. That’s a lot of money to set up one of these radios on 6 different frequencies these days. The manual states that the receiver crystal must be 455 Kc above the desired receiver operating frequency; the transmitter crystal must be on the actual operating frequency.
However there is no reason why the receiver LO crystal could not be below the channel frequency by 455 Kc as well – as long as the LO L/C circuits can be adjusted that low. The tuned IF amplifier just amplifies the difference between the LO and the signal, (or vice-versa), 455 Kc. So I am using a 3530 Kc crystal to put the receiver on 3985 Kc, one of our local military AM radio net frequencies. It works just fine.
Designed for CR-18A/U (HC-6/U holder) types, the set came with adapters to permit the CR-18A/U crystals to be inserted into the larger sockets. The installed sockets are the familiar “dual” A/B bakelite sockets also used in other sets directly for FT-243’s.
The presence of these FT-243 holder-compatible sockets may lead one to believe the set was designed to use FT-243 crystals because, well, they fit. The manual is of course silent on the use of FT-243’s versus the specified CR-18A/U crystals. So I now believe that the “design” to use FT-243 holder crystals is an unfounded assumption. More to follow on that.
The sets came from the manufacturer to operate on the following channel frequencies: 3.000, 4.060. 5.100, 6.000, 7.000 and 8.000 mc. Note that 5.0 was not included, presumably because of the presence of many frequency/time-standard stations operating on that frequency worldwide. Interference avoidance? Also, 4.060 seems to be an odd choice.
Those 6 frequencies are not “military channels” as some have stated. I think those were supplied by the manufacturer, via specific contract requirements, to provide a radio that was tuned up and demonstrably working across the full range of the radio. Having some specific test crystals installed at the factory would permit a Signal Corps QA inspector to perform a full-function acceptance test before shipping. Otherwise, no-can-do.
Once the radio got out to a Line unit, the technicians could quickly test it for proper operation, then install the assigned channel frequency crystals required by their CEOI/Comm Plan and discard the ones provided. (No tech worthy of the name would throw them away!)
An interesting note is the frequencies used in the voice-modified TRC-77 and TRC-88 tests in Thailand. Those were:
3567, 4887, 4908, 5465, 6505 and 7362 kc. Certainly not the “stock” “military” channels. (Reference 67).
Having the radio pre-tuned at the factory to those six “whole” mc channels would make retuning to a specific, nearby operational channel somewhat simpler for the technicians. Just speculation on my part but that would make sense.
Of course if the Army supply system failed to deliver the required crystals per your Comm Plan frequencies, you still had an operable radio on those “stock/test” channels. (If you are using this radio set operationally, you are pretty much at the far end of the logistics train – you know, it’s where YOU are located.) Take it up with the theatre Joint Frequency Coordinator and G-4/G-6 Shops.
“Items that must work together cannot be shipped together” Murphy’s Laws of Combat
It is known (Reference 7) that the crystal controlled AN/GRC-109’s employed in Vietnam were operated on separate transmit and receive frequencies (at least by US Navy PTF boats conducting unconventional warfare operations “up north”). I would assume the same procedure would be used with the AN/TRC-77 where ever it may have been deployed at the time. Independently selectable transmit and receive frequencies simplifies operating in that mode. Good, time-tested Fieldcraft for covert or tactical CW communications networks.
Today: With some preliminary checkout I find that the receiver local oscillator works well with the CR-18A/U crystals (HC-6/U package) or FT-243’s. However the transmitter Pierce oscillator seems to be more fussy. Putting a high impedance scope probe on either the grid or plate of the 3B4 oscillator tube kills the oscillation, odd for a low frequency circuit like this.
I have tried 8 or 10 original, “known-good” FT-243 crystals (80 and 40 meter frequencies). However the oscillator won’t start up with many of them on 80 meters, and none will work on 40 meters. Hmmmm The circuit seems to be very sensitive to stray capacitances. There is about 5-6 inches of hookup wire between the transmitter crystal sockets and the oscillator tube, via the channel switch, plus more going to the plate tank circuits and switch. No PCB, all hard-wired. Lots of stray L and C around.
See the long crystal lead wires all laced tightly together in the chassis photo below. There are additional long wires to the tuning inductors (under the shield) and back to the 3B4 as well. What to do?
I am evaluating modern, parallel resonance crystals in the HC-49 wire-lead package in the transmitter. These crystals are physically pretty small so their heating response in a different keyed oscillator circuit may produce some chirp or longer term drift. That would depend upon the crystal current in a particular circuit with these crystals.
In the TRC-77 the oscillator runs continuously on transmit (only the PA is keyed) so no detectable chirp. However, with some HC-49 crystals the frequency drifts a few tens of cycles when the radio is initially switched from receive to transmit as the crystal current begins to heat it. The filament of the 3B4 oscillator “instant heating” cathode is also coming up to temperature at the same time. By the time I am on the key, it has settled down. Give it a couple of seconds. I currently have the following frequencies installed; subject to change:
Channel 1) 3550 West Coast MRCG Agent Guard Channel (nights)
Channel 2) 3560 (Classified)
Channel 3) 7030 Current QRP Channel
Channel 4) 7040 Original QRP Channel
Channel 5) 7050 West Coast MRCG Agent Guard Channel (days)
Channel 6) 7055 SKCC Day/Evening Working Frequency
I have a pretty good selection of original FT-243 crystals but the more common ones are allocated to my GRC-109, GRC-9 and RS-6 field set kits. But FT-243’s don’t seem to work well in this transmitter. Even with different, “known good” 3B4 oscillator tubes. Surprising. So I ordered some transmit crystals from qrpme.com and expandedspectrumsystems.com. They have a good selection of the popular CW transmit frequencies but they are the miniature HC-49 wire-lead types. Improvise, Adapt, Overcome. They cost less than $3.00 each.
To evaluate them I just tack-soldered them to the underside of the 6 transmit crystal sockets as shown in the photo. In this particular circuit, the oscillation is about 1 Kc below the marked frequency, this may be due to the large series inductance of the associated wiring in this transmitter. The material on the Expanded Spectrum Systems webpage states that the HC-49 crystal specs are for an “18 pf” circuit. The operating test specification for the supplied CR-18A/U crystals is in a 32 pf circuit. That may explain the lower frequency oscillation of the HC-49 crystals in this radio.
I could add a variable trimmer capacitor in series with each crystal but that is a complication and there is little room for that. So I just inserted a single, small ceramic variable capacitor in the common lead feeding the grid (Pin 3) of the oscillator tube. Improvise, adapt, overcome.
When adjusted, this capacitor causes the oscillation of all transmit crystal frequencies to move up to within 100 cps or less of the desired (marked) frequency. Close enough for a ship this size. And for my buddies’ vintage military receivers that are similarly about 5-6 Kc (-6db) wide.
I bought six CR-18A/U crystals from International Crystal Manufacturing (Catalog number 60850) as my only option for the custom-made receiver crystals at this point. At $25.58 each. Ouch. But they work fine.
(Note: In the spring of 2017 International Crystal Manufacturing went out of business, much to our collective consternation. Presently looking for alternate sources or solutions.)
Above: The HC-49 crystals tack-soldered directly to the undersides of the crystal sockets. Note the long (colorful) crystal leads (two per crystal) to the Channel switch. The common wiper lead from this switch is the green wire going up to the oscillator tube grid. Note the variable trimmer capacitor soldered in series with this lead to the tube socket. Tack-soldered together for evaluation, this arrangement is simple and works well. The transmitter keys cleanly, no chirp, full power out. Time to head for the hills….
CRYSTALS UPDATE: I recently revived a rare AN/TRC-88 transceiver. It is very similar to the TRC-77 however it includes an Upper Sideband voice capability as well. Since ICM is no longer available to manufacture custom made crystals I tried the Epson programmable crystal oscillator circuits. For a look on how that worked take a look here, it was quite successful and should easily work in a TRC-77 or other crystal controlled receiver or transmitter system: Programmable oscillators in my TRC-88.
Above: The second field trial of the TRC-77, here chatting with Net Control. We were up on a tree-less hilltop on the Camp San Luis Obispo National Guard base during the Military Radio Collectors Group 2015 event. We also had an ARC Type 12 set on 144.450 mc AM and a PRC-25 on 51.00 mc FM, both voice. The TRC-77 was operating on 3550 Kc CW and connected with Net Control at the base in the background of this image. Net Control was operating an MRC-56 communications trailer equipped with an ARC-1 VHF AM set as well as a TCS on CW. Hardly “DX” but good comms all around.
The TRC-77 was driving a 32′ horizontal wire antenna against a similar wire counterpoise laying on the ground. The antenna end was held up at about 15 feet by a bamboo pole lashed to a “support of opportunity” as seen below. A direct-wave path for sure but reports were that the TRC-77 sounded solid with a clean CW tone. As one would expect.
Above: An antenna with a view. That’s the Pacific Ocean on the far horizon. This low antenna is nearly ideal for regional (0-300 km) NVIS operation on an appropriate frequency at an appropriate time of day. Otherwise it is also good for local “direct” or “ground wave” propagation.
More “off-grid” evaluations: ARRL Field Day 2015
Above: Running both the TRC-77A (in the ALICE pack) and GRC-109 sets on both 40 and 80 meters CW using an Inverted “L” antenna and a ground stake with radial wires. Good comms up and down the west coast, including with Andy in Salinas running his PRC-174 for some initial CW contacts with that set. The ME-61/GRC Field Strength Meter came in handy in adjusting the GRC-109 transmitter to that high impedance antenna on 40 meters. Not enough antenna current available to illuminate the “Tuning” lamp. Lots of RF however…
Above: Radioactive cabin camping.
Above: The TRC-77 (on left) doing what it does best. The “Battalion Communications Center” at my hasty campsite in the Sierra Nevada mountains for ARRL Field Day 2017. Driving a dipole from a remote site keeping in touch with my buddies 200 miles away…twenty miles from the nearest cell phone “signal”, ten miles from the nearest paved road.
Fair Radio Sales was carrying the TRC-77 in their 1981 Catalog and Supplement for $75. But setting up a TRC-77 today on 6 Ham frequencies could cost a few hundred dollars +, just in crystals. (IF you can get them.) I think that, and the lack of a tunable receiver has significantly limited the interest from the Ham community in these sets, not to mention the large number of today’s Hams that just operate FM repeater or maybe SSB voice radios. CW? What’s that?
“Yeah – it weighs 5 times more than my plastic KenYaeIc Ricebox and it doesn’t have dual VFO’s, digital readout, variable color dead-columns-of-death LCD display, DSP, roofing filters, a 15 band voice equalizer, 100 watts, RF Preamp, Bandscope, VHF/UHF, microprocessor controls, menus, RF processor, direct frequency entry, 500 memories, WiFi, Bluetooth, free software APP’s, selectable sidebands, auto QSO’s or anything. It won’t even enable my computer to automatically text “599” to your computer! You have to actually operate it! Whatta piece of junk! ” Exactly.
Or, as my buddy told me, “Nothing says BadAss like a field set with no microphone connector.” Didididit didit !
Cartoon by Andy.
“You see, wireless telegraph is a kind of a very, very long cat. You pull his tail in New York and his head is meowing in Los Angeles. Do you understand this? And radio operates exactly the same way: you send signals here, they receive them there. The only difference is that there is no cat.” Albert Einstein.
AR
Hello,
Put a picture on my (new) website from de accesoiries bag TRC77.
Compliments for your website.
Hans
Hi Hans – Thanks for visiting my website! Yours is great – I especially like your layout. That TAR-224 was quite a find! Serial 001….. The TRC-77 accessory bag is pretty big but I wonder why there was no carrying harness or bag for the radio itself. Since it could not be operated while in motion perhaps this was the reason – just carry it on a pack board or in the regular field pack with everything else. At least the weight could be distributed between 2 soldiers who could carry the radio and battery independently.
Another interesting CW set.
73 and have fun!
Tim
Tim et. Al,
I’ve seen a picture of U.S. Rangers carrying the TRC-77. One had the radio, another had the battery box. The caption didn’t say anything about the accessories, I suspect they were distributed to the rest of the squad to carry in their ruck sacks. They had packs with frames, and the bag was low on their backs.
Thanks again for your website.
Sean
Hi Sean – Can you find a link to that photo, I may have seen it as well. I understand that the modern-era Rangers were given that title after the existing LRRPS in Vietnam were redesignated as Rangers in 1969. That may have occurred after the TRC-77 continued to fade into oblivion in the mid-1960’s. So Rangers (or anyone else) carrying a TRC-77 would be interesting to see. I have seen the photo of Special Forces guys evaluating the (mis-identified) TRC-77 alongside the PRC-64 in Vietnam, the only instance I can find of its presence there. (Reference 52, page 69) Anyone??
Thanks, Tim
Very nice review of the background on these great sets. I have had 3 of them over the years. currently have one set up in my reading den to monitor the 80 meter frequency of my ragchew group on the low end. The antenna (for rx only) is a ten foot wire hanging out of the window. Battery is a 14 amp Gel cell. I got 2 of mine in the mid 70’s, new in the cartons, at $50.00 apiece. The third was a $20 hamfest purchase, also looked like new. Never seen one that looked like it saw service…….
Frank
Hi Frank – Thanks for that input! I didn’t know they were “available” back then or what they had been selling for. Good intel….I think your experience with not seeing beat up radios is fairly consistent with what I have seen – not many obvious service veterans. There may be a bunch of them around but I have never heard one on the air. I think this is due to the crystal controlled receiver – not a band cruiser like we are most used to…I think they are very interesting and capable sets and great for a “buddy net” on a fixed freq. I still need to get some appropriate RX crystals to match the transmitter rocks that I do have..
Thanks for visiting my website and have fun with your 77….
73, Tim
Very interesting article on TRC 77.
A good ideas for battery case.
best 73 de ik5dgf
Hi Silvio – The TRC-77 is an interesting set and it works very well. We did a “field test” this weekend and received good signal reports.
Thanks for visiting my website!
73 and Ciao!
Tim
Tim,
BZ on the TRC-77 report. But what were the Lurps doing in Southern Europe in 1962? 73 de Bart, K6VK ##
Sending Morse Code? LOL
Prolly reconning the eastern approaches to the Fulda Gap ….
Thanks Bart es 73, T
Tim, you [had] said: “I can find no references indicating they were ever issued to Special Forces units per se, even for evaluation. That said however, these sets would have certainly caught the attention of Special Forces and others.”
Well, look at page 69 of Special Forces At War by Shelby Stanton, 1990, reprinted 2008. Top right photo shows a PRC-64 and a TRC-77 misidentified as a PRC-77. The cutouts on the battery box are unmistakably for the TRC-77 and the op is wearing a knee key. Caption says “Special Forces radiomen tested two high-frequency radios in Vietnam from October 1964 through January 1965: the lightweight PRC-64 and an experimental PRC-77 radio set.” Photo is identified as “Author’s Collection.” A second photo on the same page is supposed to show those two test sets in a 1964 rainstorm but it is too muddy to make out much. He must have mixed up the TRC and PRC 77 since the PRC is not an HF set. Email if you can’t find the book and would like a PDF of this page.
Bill W8FIX
Hi Bill – You have a sharp eye! I stand corrected.
I had not seen that book reference before. You’re right, the author mis-identified it as the PRC-77 so it did not show up in my searches for the TRC-77. (He also mis-identified the PRC-74 as the “GRC-74”. Easy mistakes to make well after the fact.)
It is a TRC-77 in the photo for sure though. According to the author it was being evaluated alongside the PRC-64, probably the same comparison tests done earlier in Panama and Thailand. That would make sense. I wonder if it is the same “experimental” TRC-77 that was being evaluated by DARPA in Thailand in 1963. (That TRC-77 being a TRC-77 modified to include AM voice operation). I need to do some more digging…
Thanks for passing that along! I will add that book to my reference list and I have modified the article accordingly.
Hello Tim,
Very interesting article, thanks for making it available. I have a TRC-77 which I am trying to get going and your article will be a big help. When I do get it up and running, maybe we will be able to have a qso with it. I’m located in Flagstaff, AZ. Looks like we have some similar interests.
My tech shop is being remodeled at this time but I will hopefully be back into it soon.
73 Rich NN7D
Hi Rich – OK, glad you found the post useful… Sure, when you are ready, shoot me an E Mail and we can set up a shakedown cruise for your 77. Flagstaff should be fairly easy from here (I’m near Oakland CA)..
They are fun bush radios and they work very well…
Thanks for stopping by
73, Tim
Great article. You’ve done some ‘heavy lifting’ with your research.
Thanks
73 Blair
Hi Blair – Well, thanks! Researching the history and deployment of this gear sure is part of the fun. “Just imagine…”
Thanks for stopping by, 73
Tim
For a quick and easy battery box, remove the case from your spare TRC-77 if you have one and snap it on the bottom of your main TRC-77. The latches fit perfectly. Remove and save the connector from the bottom of the box so it doesn’t wobble. Done. The field expedient battery box is only 3/4″ taller than the real one.
Bravo! Good eye…..Now to find a spare TRC-77! Thanks Bill
73
I served in Co C (LRP) 58th Inf. (VII Corps) originally USA LRRP Co 3780 and later B Co 75th Rangers. Cross trained as a RTO in a base station and patrols and was also school trained in Commo equip maintenance plus also served as a CW instructor in our in-house CW training facility the “Dit Pit”. LRRPs were tasked with Surveillance and Target acquisition behind enemy lines (for extended periods with no re-supply or extraction and with patrol personnel expected to perform their assigned mission and were considered expendable -Lt Col Mitchell’s (then a 2nd Lt) exact words since it was his job to select personnel who could perform a specific mission(s) but were considered expendable. On completion of their assigned mission(s), personnel would then be written off the books-SGM Rowe Attaway’s exact words-. After a mission, LRRPs would have to make their way back to friendly lines as best they could. With surveillance missions that could range from a few miles to up to 300 miles LRRP personnel had to be exceptional individuals. Under Maj Maltese and Maj Hunt CW proficiency was considered the most important part of the LRRPs. Cross-training by all patrol members was required. “What good was information if the radio telegraph operator (RTO) was shot up and the rest of the patrol couldn’t communicate in CW”- Maj Hunt’s words. Local CW training for all LRRPs was required. We had the “Dit Pit” a complete CW training class room in the basement of our barracks at Nellingen Barracks (aka Nellingen Kasern). All personnel (Officers and EMs) were required to be CW trained to at least 5 wpm minimum (most RTO’s were comfortable at 20 wpm but a few exceeded this). The company was diverse, we had several former Marines (Col Bingham (ret.) – a Korean war decorated Marine Vet-being one of them) at least one Navy plus a few had seen service in foreign armies. Most Officers and NCO’s were either Ranger or Special Forces trained (or both). Quite a few went on to Ranger and SF training (those not already trained) at least one later served in the Delta Force. Several eventually were recruited and served as CIA operatives. Due to the extensive communications training the VII Corps LRRPs were considered the best trained CW operators in Europe. Major Maltese (WWII OSS and later served in early SF under Col Aaron Bank) and Major Hunt were both WWII Veterans with Hunt being highly decorated. The training was modeled on WWII OSS and SF training. LRRP volunteers had to go through a selection process that weeded out those not qualified for the LRRP mission. Under Col Maltese (ret. deceased) and Col Hunt (ret. deceased) VII Corps LRRPs had no problems with the TRC-77 due to the extensive training. According to Col Hunt it could take as much as 8 months of training for LRRP personnel to meet the communications requirements of the company’s mission. The TRC-77 worked very well for us due to the extensive communications training provided. The lack of proper training resulted in most “OTHER” units giving the TRC-77 a bad rap. In mid ’67 the TRC-77 began to be phased out being replaced with the PRC-74 and more use of the GRA71 burst unit that made split frequency communications out-dated due to much improved radio direction finding and triangulation equipment available. Many of the VII Corps LRRPs went on to serve exceptionally in Vietnam with one former VII Corps LRRP, Sgt Glenn H English, awarded the Medal of Honor (posthumously). –Soldier ON! (Sam–KD6S)
Hi Sam – Thanks for your info! Nothing like “ground truth” from people who used this kind of gear operationally. Sounds like it served the missions in Europe well. I wonder if you ever had a need to use the GRA-71 burst keyer with the TRC-77 or was that keyer used more with the later PRC-74 sets.
Any details on how the TRC-77 was utilized on LRRP missions such as range, reliability etc. Antennas successfully employed? There is really very little information on the operational use of the TRC-77’s “out there”.
Thanks for checking in! Tim
Sam,
In your LRRP procedures, did your messages involve a callup and/or acknowledgement or were they sent blind?
Thanks, Rob
Hello Tim
Thanks for the nice page on trc 77, I have one of these nice radios and now I’m looking for the crystal to get it operational on qrp frequencies here in Europe.
I’m active only on A1 , so I like a lot this manpack rtx, no sincgars and bell and whistles .
Regards and 73 Emanuel
Hi Emanuel – Many thanks for your interest in the TRC-77 and hope you can get the crystals you need. They are fun to operate!
Thanks for stopping by my website, 73
Ciao! Tim
Hi Tim,
I recently snagged a TRC77 in decent shape. I’d like to make a power cable for it but I’m having some trouble identifying what kind of connecter is on the back of the cover. I was hoping you might be able to point me in the right direction.
Its the 8 pin round connector. It looks like pins 2, 3 and 4 provide 12VDC and pins 5, 6 and 7 go to ground. Pin 1 appears to not be connected. I posted a few photos here:
https://imgur.com/a/36wzzot
Thanks,
Robert
AD0TA
Hi Robert – Sorry for the late reply. Yes, you have a “non-A” model with the 8 pin power connector, you have identified the pins correctly. I don’t know what the mating connector is, the manual does not specify it. I had to jury-rig one for a friend, used Molex female sockets and heat shrink tubing, you could also try small brass tubing from a hobby shop.
Sorry I can’t be of more help…Tim
What an outstanding site!!!!!!!
OBTW: I was the “author” of the ARRL’s Low Power Communications….the 3rd edition was the one featuring a lot of MilCom gear. Thanks for the plug.
I had two (2) TRC-77As….one a project rig and the other one fully operational on all 6 chnls and when I bought the Xtals from ICM they were just shy of $30/each! Love your solution using the smaller Xtals soldered to the Xtal sockets. Great idea.
Now I am in the market for another TRC-77/77A….I ended up selling off my two when we moved from NEPA to Atlanta, GA. Also sold off my TRC-74B which was complete and included a USB mod. Man, I miss that radio!!!
Anyway, I have a couple of leads on the 77s….the prices wander all over the place….may have one in exchange for a T-T Argonaut 509 that I have restored. Have to see about that. Allegedly it has some ham xtals already in place.
Again, many thanks for this section on the 77s. I learned a lot just by reading thru the site. You and I need to get together….planning on doing a FD with the Zuni Loop Expeditionary Force on Table Mt. outside LA in 2 yrs. Maybe we can arrange to meet then.
Vy 73
Rich K7SZ
Hi Rich – Well using these old radios and studying their history and operational lives has always been an interesting nexus for me. The website has been a good place for me to stash photos and research details before I forget it all! haha.
Good luck on your search & thanks for visiting my site..
Hi Tim:
Just reading over the history of the 77. I have had several GRC-109 sets. They are sorta cool ‘cept for the fact that they are big and heavy!!
While working with Special Operations Task Force Europe (SOTFE), and 10th Group out of Bad-Tolz I was told several times that there were a bunch of GRC-109s sealed up in the walls of safe houses in E. Berlin!! So….if we could only get some round trip tickets to Berlin and a line on those houses while dragging along a sledge hammer and a pick-ax, we could be in the GRC-109 business!
Vy 73
Rich K7SZ
Hi Rich – Well SOP would have lots of caches scattered around interesting places…Inside the walls of suitable buildings is a consistent story. My GRC-109 post shows photos of a cache recovered in Norway with an RS-1 set. Also take a look at my RS-6 post – there are photo’s of an RS-6 set that was found cached in Austria, it included spares and crypto materials. That one is pretty interesting; it was sold on EBay !!
Hi s I wonder whether one or some of the chaps experienced with use/servicing of the TRC 77 might drop me a line at goldmort@onthenet.com.au.
I have one with some of the gear….Particularly handy are (humour) a throat mic and a carbon mic from the Ming dynasty …but there are antenna and plugs…and a couple of alignment tools. I’m even lucky enough to have a battery box cover !!….maybe one day a battery box will be found…or Santa will bring one…I’m not sure whether the 77 are the same as the SASR cw- only ‘brick’ used in Vietnam.
Would perhaps some experienced person/persons get in touch and work with me to get the set up and running?
I’ll have to change some caps as the two large 1 uFds are o/c or very high resistence…the smaller ones likely to also be kaput….they measure but too far out of whatever value they were when new…the 4000u Fd also.
I’ve had the set a while. I don’t want to solder-in crystals…I have one adaptor and a few crystals of that base type …one 6995 the others are from the walkie talkie (BC611)?)…I can use them in testing. I know the 77 is 455 intermediate but not sure whether below or above crystal frequency
I’m not sure of the IF situation of the 611, I think it is 455 above crystal frequency and it’s probably irrelevant insofar as just running the 77 it up on Rx with something in it to oscillate.
From Australia a couple of perhaps interesting read, not prc 77 but interesting..s:
http://pronto.au104.org/Pronto_Book/ProntoSVN_CH2_2012.pdf
https://www.qrz.com/db/VK2BLC#t_logbook
Hi Tony – Thanks for stopping by! OK on the TRC-77, I have “revived” 4 of them and none* needed any capacitor replacements. Maybe I’m just lucky but the parts seem to be of high quality otherwise… The soldered-in crystals was a necessity owing to the difficulty in finding suitable crystals of the proper spec. But they work and could be inserted in correct “packages” if optics were a consideration.
The IF freq is 455 and I found that high or low side injection works if the LO oscillator circuit can be tuned (as in below 3.045 mc if working in the 3.5 mc CW band.) Otherwise the mixer does not seem to care, the IF amp takes the output either way.
Pretty much everything I have found or learned about the TRC-77 is in my web post but I would be glad to help further if I can. BTW, your QRZ website is great! WOW! I really like your mobile setup…. Also thanks for the Pronto link – very interesting. I had read it awhile back while researching PRC-47 deployments. Well done!
(*Update/Correction: I did replace a 22uF emitter bypass cap in the AF amplifier stage in a 77A set. It was causing intermittent static/scratching noises during receive.)
Thanks – let’s get your TRC-77 going!
Cheers, Tim
Tim,
Expanded Spectrum Systems is still offering crystals on five of the frequencies you installed. SKCC says slow code should be -2 KC. I wonder if a person could have a second “common” lead to pull those frequencies down that much?
I found these, too:
https://www.pixiekits.com/product/2x-hc49-s-qrp-ham-radio-crystals-great-for-your-pixie/
Hi Tim …yes I think I was wrong on the caps. I just did a quick check and am getting some results on Rx. My regards
Hi, I recently purchased a complete and in fair conditions TRC-77 and made a custom power cable for it being the original one not available.
However, the radio does not power up but when I switch to TX without pushing the morse key I can see anyway abt. 2A of current draw.
Any idea where to look at ? (I have unfortunately no lab instruments and little experience…..😥)
Tnx for help es 73
Alex, HB9DTA
Hi Alex – PM sent with a few questions.
Cheers! Tim
I have 5 of these radios to get on the air and hopes one day to work N6CC out in the valley
The battery box is the challenge for some odd reason
John
Great blogpost
Hi John – Yes the battery boxes are kind of rare, “Battery juice” eats them!
Looks like we have lots in common – Have fun and thanks for visiting…Tim
Hey Tim,
Well, I finally got around to rebuilding the toroid loading coil sitting on the back of the antenna tune switch. Not sure if you remember the inductor was arching between windings while transmitting. Had to do a complete breakdown of the front panel assembly to get at the switch for removal. All in all took maybe 3hrs start to finish wasn’t too bad of a job just a bit apprehensive at first removing the front panel and rewinding the inductor wasn’t bad either.
Tnx Dave
W6MQI
NNNN
Hi Dave – Good on ya! Very tight in there, glad you were able to make the repair, I hope mine continues to hold up but so far no arcing in that coil with the antennas I normally use. Just takes a little nick in the enamel wire coating. See you on 3550! Tim
Tim
I just acquired a TRC-77 and I am looking forward to playing with it. I was wondering what latches you used on your battery box? Also, how does a PRC-77 battery box measure up compared to the TRC-77? The radios look about the same size. I know it probably would not leave much battery room, but I might have one laying around that I could steal the latches from.
I am planning to try the QRP labs prog rock 2 in the TRC when it gets here. I have used one successfully in an SEM-52 on 51 meg and it seems to work ok. The best part is that they are 18 bucks and you can digitally address the prog rock to select one of a number of preprogrammed frequencies. You can also program them easily through USB. It should not be much trouble to use the existing channel switches to do so.
Now, if I can figure out a good way to plate modulate the 2E24, then I should be good to go.
Hi Anthony – Good deal on your TRC-77. Yep, if I had to do it again I would use one of those Prog Rock synthesizers, looks like an ideal solution with a little additional engineering to integrate it. (Plus it is small!) As to battery box latches I think I got mine at a swap meet but maybe from McMaster-Carr, it’s been awhile…They have a big selection of various types, even those that look identical to those used on the PRC-77 if you want to go that route.. Yep a plate modulator design would be fun but you’ll need a bigger battery box! hihi
73, Tim
This unit was installed in our Civil Air Patrol Jeep back in the 70s.
super votre description
jacques F4IER
Merci de votre visite!
Tim
